5 Operation
42
5.2.6 Service
This menu contains various service functions.
Default configuration
You can store the current device configuration with this function.
Similarly, a previously stored configuration can be loaded as the current configuration.
5.2.7 Calibrating the touchscreen
This menu enables you to calibrate the touchscreen (position calibration). To do so, you need to tap the
center of the crosshairs shown in the corners of the screen one after another.
5.3 Alarm and event menu
The alarm and event menu enables you to call up the alarm list and event list.
View
Alarm and event lists of the batches
A separate alarm list and event list exists for each active batch (in addition to the overall list). These sep-
arate lists contain batch-related entries based on the group assignment (events and alarms of the chan-
nels and counters/integrators).
(1) Menu items
(2) Quit the alarm and event menu
