JUMO LOGOSCREEN 601 - Digital Channels; Diagram View

161
7 Configuration
7.18.3 Digital channels
A group can consist of up to six digital channels (Channel 1 to Channel 6).
Device dialog box
Parameter
7.18.4 Diagram view
Device dialog box
Parameter Selection/settings Description
Input signal Digital selector
No selection
Signal source for the channel
