7 Configuration
94
7.1.2 Digital selector
Category Signal Description
No selection No signal selected
Digital inputs Digital input 1 to 12 Signal of digital input
Digital inputs/
outputs
Digital input/output 1 to 12 Signal of digital input
External digital in-
puts
Ext. digital input 1 to 24 Signal of external digital input (via interface)
Math results (digi-
tal)
Math (digital) 1 to 6 0 = Math result is valid
1 = Math result is invalid (computation error,
also for substitute value output)
Logic results Logic 1 to 6 Results of logic formula
Signals of limit
value monitor.
Status of limit value monit. 1 to 24 Status signal of limit value monitoring function
Alarms of digital
inputs
Alarm digital input 1 to 12 Alarm signal of the digital input
Alarms of digital
inputs/outputs
Alarm digital inputs/outputs
1to12
Alarm signal of the digital input
Alarms of analog
inputs
Alarm 1 analog inp. 1 to 6 Alarm signal from alarm 1 of the analog input
Alarm 2 analog inp. 1 to 6 Alarm signal from alarm 2 of the analog input
Alarms of ext. dig-
ital inputs
Alarm ext. digital input 1 to 24 Alarm signal of external digital input
Alarms of ext. an-
alog inputs
Alarm 1 ext. analog input 1 to 24 Alarm signal from alarm 1 of the external ana-
log input
Alarm 2 ext. analog input 1 to 24 Alarm signal from alarm 2 of the external ana-
log input
Alarms of logic Alarm logic 1 to 6 Alarm signal of logic formula
Alarms of math Alarm 1 math 1 to 6 Alarm signal from alarm 1 of math formula
Alarm 2 math 1 to 6 Alarm signal from alarm 2 of math formula
Alarms of limit
value monitor.
Alarm limit value monit. 1 to 24 Alarm signal of limit value monitoring function
Alarms of flow Alarm 1 flow 1 to 2 Alarm signal from alarm 1 of flow measurement
Alarm 2 flow 1 to 2 Alarm signal from alarm 2 of flow measurement
Alarms of count-
ers/integrators
Alarm 1 counter/integr. 1 to 6 Alarm signal from alarm 1 of counter or integra-
tor
Alarm 2 counter/integr. 1 to 6 Alarm signal from alarm 2 of counter or integra-
tor
Alarms of groups Upper tol. alarm gr. 1 to 4 Upper tolerance band alarm signal of group
Lower tol. alarm gr. 1 to 4 Lower tolerance band alarm signal of group
Alarm group 1 to 4 Collective alarm of group
