JUMO LOGOSCREEN 601 User Manual

95
7 Configuration
System alarms Collective alarm Collective alarm of device
The signal is active if the alarm list contains at
least one entry (an entry is removed as soon as
the alarm disappears).
Collective alarm with acknowledg-
ment
Collective alarm of device; active until acknowl-
edged
The signal is activated for each new entry in the
alarm list; it remains active until acknowledged
(even if the entry has disappeared from the
alarm list).
Memory alarm The signal is active if the data was not read out
in time and the free internal memory drops be-
low the memory alarm limit value (Configura-
tion > Device).
Battery empty Battery alarm (buffer battery is discharged and
must be replaced)
Notify service department!
Caution: RAM memory content may be lost!
Battery weak Battery pre-warning (buffer battery can be re-
placed within 4 weeks without data loss)
Notify service department!
User logged on Signal is active when a user is logged on.
USB flash drive active This signal is active if a USB flash drive is
plugged in and active.
Temp. unit °F device This signal is active if the temperature unit of
the device is configured as "Degrees Fahren-
heit" (Configuration > Device).
Temp. unit °F interface This signal is active if the temperature unit of
the interface is configured as "Degrees Fahren-
heit" (Configuration > Device).
The following "Slave timeout ..." signals are active if the device is acting as a Mod-
bus slave, timeout monitoring is enabled, and no request is received from the Mod-
bus master within the configured period (Configuration > Serial interface;
Configuration > Modbus/TCP).
Slave timeout Com1 (for Modbus via serial interface)
Slave timeout Com1 inv (as above, inverted signal)
Slave timeout TCP1 (for Modbus-TCP, master 1)
Slave timeout TCP1 inv (as above, inverted signal)
Slave timeout TCP2 (for Modbus-TCP, master 2)
Slave timeout TCP2 inv (as above, inverted signal)
Batches Batch 1 active Signal active when batch reporting is active
Alarm batch 1 Alarm signal of batch reporting
ST code digital
outputs
ST digital output 1 to 40 Signal of the digital output from the PLC module
(application created with ST code)
ST code alarm
outputs
ST alarm output 1 to 32 Alarm signal from the PLC module (application
created with ST code)
ST code error ST error Error signal from the PLC module (application
created with ST code)
Category Signal Description
