Page #92 background imageLoading...
Page #92 background image
7 Configuration
92
Overview of inputs and outputs and internal functions
The following table provides an overview of all inputs and outputs, as well as the internal functions with
digital or analog output signals. The number of optional inputs and outputs depends on the device ver-
sion (see order details, options 1 to 3).
Inputs/outputs/functions Notes
Analog inputs 1 to 6 Optional extra
Analog outputs 1 to 2 Optional extra
Digital inputs 1 to 12 Optional extra
Digital inputs/outputs 1 to 12 Optional extra, can be switched individually
Relay outputs (changeover contact) 1 As a standard feature
External analog inputs 1 to 24 As a standard feature, via interface
External digital inputs 1 to 24 As a standard feature, via interface
External text variables 1 to 10 As a standard feature, via interface
External event texts 1 to 4 As a standard feature, via interface; 1 text per
group
Limit value monitoring functions 1 to 24 As a standard feature
Counters/integrators 1 to 6 As a standard feature; incl. 2 high-speed counters
(via digital inputs/outputs 1, 2)
Flow measurements 1 to 2 As a standard feature; high-speed inputs are re-
quired for the "Digital" signal type
Math functions 1 to 6 Optional extra (extra code 260)
Logic functions 1 to 6 Optional extra (extra code 260)
ST code
- ST analog outputs 1 to 40
- ST digital outputs 1 to 40
- ST alarm outputs 1 to 32
- ST fault output
Optional extra (extra code 221); see
chapter 9.10 "ST code", Page 223
