7 Configuration
164
Memory status
The operating mode "Standard operation" is only available if memory status is switched on.
NOTE!
If the memory status is switched off and neither event operation nor time operation is active, only events
will be recorded but measurement data will not be saved.
Memory values
For a digital signal the following values are stored depending on the "Memory values" parameter:
Memory cycle 0 s ... 5s... 32000 s The memory cycle is configured here.
Depending on the configuration of the
"Memory values" parameter, the mea-
surement data is saved when the config-
ured time has elapsed. The smaller the
memory cycle, the more data needs to
be saved.
If "0 s" is configured, the device uses the
fastest possible cycle; in other words, it
stores the measured values every
125 ms (high-speed mode; possible for
up to four groups).
Parameter Selection/settings Description
"Memory values" parameter Stored value
Average value High (1), if the digital signal assumes this value once during the
memory cycle, otherwise Low (0)
Current value Current value at the time of storing
Min. value Low (0), if the digital signal assumes this value once during the
memory cycle, otherwise High (1)
Max. value High (1), if the digital signal assumes this value once during the
memory cycle, otherwise Low (0)
Min./Max. value High (1), if the digital signal assumes this value once during the
memory cycle, otherwise Low (0)
