JUMO LOGOSCREEN 601 User Manual

9 Configuration – in setup program only
224
Variables bool_out01 to bool_out40
Variables real_out01 to real_out40
Variables alarm01 to alarm08
Parameter Selection/text/value Description
Description <Enter text>
Use default text or enter
other text.
Description of the Boolean output variables
Designation <Enter text>
Use default text or enter
other text.
Abbreviation of variables
Parameter Selection/text/value Description
Description <Enter text>
Use default text or enter
other text.
Description of the real output variables
Designation <Enter text>
Use default text or enter
other text.
Abbreviation of variables
Temperature This selection is important for the automatic con-
version in case of a change in temperature unit
(°C/°F) (see system data).
None The value is not a temperature.
Relative The value is a temperature difference.
Absolute The value is a temperature value.
Unit <Enter text>
%
Value unit (if it is not a temperature)
Scaling start -99999 to 99999 (0) Minimum admissible value
Scaling end -99999 to 99999 (100) Maximum admissible value
Decimal places Number of pre-decimal and decimal places for dis-
playing the value
Auto Automatic
XXXX. No decimal place
XXX.X One decimal place
XX.XX Two decimal places
X.XXX Three decimal places
Parameter Selection/settings Description
Activation Off Alarm (signal monitoring) is inactive.
On Alarm (signal monitoring) is active.
Alarm/Event list Off In the event of an alarm, only the alarm signal is
activated.
Event The alarm/event text is entered in the event list.
Alarm The alarm/event text is entered in the alarm list
and the event list. The collective alarm is activated
and the text of the last alarm to occur is displayed
in the status bar.
?
