9 Configuration – in setup program only
230
NOTE!
A measured value outside of the definition range results in a deviation above or below the measuring
range (out of range).
Displaying linearization on a graphic ("Display graphic" button)
Use this button to create a graphic of the linearization.
The graphic includes the characteristic lines for both types of linearization where applicable, namely the
grid points (table) and the formula.
The display range for the graphic is initially determined by the smallest and largest grid points; it can be
temporarily changed in the display by entering different x values.
Calculating the polynomial using the grid points ("fx" button)
After entering the value pairs, use this button to calculate a polynomial that describes the progression of
the linearization characteristic line.
The calculated coefficients are incorporated into the formula. The characteristic lines for both types of
linearization then correspond to each other.
If the x values do not increase in a straight line, the linearization is not applied. In this case, it is impos-
sible to display the graphic or calculate the polynomial.
