SCB-MX is the first-generation switch control board. The SCB-MX is designed to work with
first-generation DPC line cards.
•
The SCBE-MX is the second generation switch control board and is designed specifically for use with
MPC3E line cards to provide full line-rate performance and redundancy without a loss of bandwidth.
•
The SCBE2-MX provides improved fabric performance for high-capacity line cards using the third
generation fabric XF2 chip (MPC4E, MPC5E, MPC2/3 NG, and MPC7E).
•
The SCBE3-MX Enhanced Switch Control Board provides improved fabric performance and bandwidth
capabilities for high-capacity line cards using the ZF-based switch fabric.
Table 4 on page 4 compares the SCB capacities of the MX Series 5G Universal Routing Platforms.
Table 71 on page 147 lists the supported routing engines per SCB.
Table 70: Switch Control Board Capacities for MX Series 5G Universal Routing Platforms (Full-Duplex)
MX960 Fabric
Bandwidth
MX480 Fabric
Bandwidth
MX240 Fabric
BandwidthFabric Bandwidth Per SlotDescription
Up to 33 TbpsUp to 18 TbpsUp to 6 TbpsUp to 1.5 Tbps (non-redundant
fabric configuration with
MPC10E line cards); 1 Tbps
(redundant fabric configuration
with MPC10E line cards)
Enhanced MX Switch
Control Board
(SCBE3-MX)
Up to 10.56 TbpsUp to 5.76 TbpsUp to 1.92 TbpsUp to 480 Gbps
(non-redundant fabric
configuration); 340 Gbps
(redundant fabric configuration)
Enhanced MX Switch
Control Board
(SCBE2-MX)
Up to 5.25 TbpsUp to 2.79 TbpsUp to 930 GbpsUp to 240 Gbps
(non-redundant fabric
configuration); 160 Gbps
(redundant fabric configuration)
Enhanced MX Switch
Control Board
(SCBE-MX)
Up to 2.6 TbpsUp to 1.39 TbpsUp to 465 GbpsUp to 240 Gbps
(non-redundant fabric
configuration); 120 Gbps
(redundant fabric configuration)
Switch Control Board
(SCB-MX)
