Table 90: FRU Power Requirements (continued)
Maximum Power
RequirementPart NumberComponent
320 WDPCE-R-40GE-TX
DPCE-X-40GE-TX
Tri-Rate Enhanced DPCor
Tri-Rate Enhanced
Ethernet Services DPC
265 WMS-DPCMultiservices DPC
Flexible PIC Concentrators (FPC)
190 W (with PICs and
optics)
MX-FPC2FPC Type 2
265 W (with PICs and
optics)
MX-FPC3FPC Type 3
RELATED DOCUMENTATION
Electrical Specifications for the MX960 DC Power Supply | 225
Electrical Specifications for the MX960 AC Power Supply | 203
Calculating Power Requirements for MX960 Routers
The information in this topic helps you determine which power supplies are suitable for various
configurations, as well as which power supplies are not suitable because output power is exceeded. You
determine suitability by subtracting the total power draw from the maximum output of the power supplies.
Afterward, the required input current is calculated. Finally, you calculate the thermal output. A sample
configuration is provided in Table 64 on page 135.
We recommend that you provision power according to the maximum input current listed in the power
supply electrical specifications (see “Electrical Specifications for the MX960 AC Power Supply” on page 203
and “Electrical Specifications for the MX960 DC Power Supply” on page 225).
Use the following procedures to calculate the power requirement:
1. Calculate the power requirement.
2. Evaluate the power budget.
215
