Juniper MX960 Hardware Guide

Installing an MX480 Routing Engine
“Installing an MX960 Routing Engine” on page 385
Install the SCBE3-MX into the Router Chassis
Refer to the Switch Control Board installation procedure for your MX model:
Installing an MX240 Switch Control Board
Installing an MX480 Switch Control Board
“Installing an MX960 Switch Control Board” on page 387
Complete the SCBE3-MX Upgrade
1. Verify that the installation is successful and the SCBE3-MX is online:
user@host> show chassis environment cb 0
CB 0 status
State Online
Temperature 30 degrees C / 86 degrees F
...
user@host> show chassis environment cb 1
CB 1 status
State Online
Temperature 30 degrees C / 86 degrees F
...
Other details, such as, temperature, power, etc are also displayed along with the state.
2. Verify that the fabric planes come online correctly:
user@host> show chassis fabric summary
Plane State Uptime
0 Online 2 days, 19 hours, 10 minutes, 9 seconds
1 Online 2 days, 19 hours, 10 minutes, 9 seconds
...
3. Verify that the backup Routing Engine is back online:
585

Juniper MX960 Specifications

General

Power Supply	AC or DC
Redundancy	Yes
Operating System	Junos OS
Form Factor	Rack-mountable
Operating Humidity	5% to 90% non-condensing
Chassis Type	Modular
Slots	12
Interfaces/Ports	Varies with line cards
Operating Temperature	0°C to 40°C (32°F to 104°F)
Routing Engine	Redundant Routing Engines
Interfaces	Supports various interface modules
