Juniper MX960 - Connector Pinouts for MX Series Routing Engine aux and CONSOLE Ports

Table 84: RJ-45 Connector Pinout for the Routing Engine ETHERNET Port
SignalPin
TX+1
TX–2
RX+3
Termination network4
Termination network5
RX–6
Termination network7
Termination network8
RELATED DOCUMENTATION
MX960 Routing Engine Description | 30
Replacing Connections to MX960 Routing Engine Interface Ports | 473
Replacing an MX960 Routing Engine | 461
RJ-45 Connector Pinouts for MX Series Routing Engine AUX and CONSOLE
Ports
The ports on the Routing Engine labeled AUX and CONSOLE are asynchronous serial interfaces that accept
an RJ-45 connector. The ports connect the Routing Engine to an auxiliary or console management device.
Table 85 on page 201 describes the RJ-45 connector pinout.
Table 85: RJ-45 Connector Pinout for the AUX and CONSOLE Ports
DescriptionSignalPin
Request to SendRTS1
Data Terminal ReadyDTR2
201
