Juniper MX960 - MX960 Fan Leds on the Craft Interface; MX960 Cable Manager Description

Table 11: SCB LEDs on the Craft Interface
DescriptionStateColorLabel
SCB: Fabric and control board functioning
normally.
On
steadily
GreenOK
SCB is transitioning online or offline.Blinking
The slot is not online.Off–
SCB has failed.On
steadily
RedFAIL
MX960 Fan LEDs on the Craft Interface
The fan LEDs are located on the top left of the craft interface. Table 12 on page 22 describes the functions
of the fan LEDs.
Table 12: Fan LEDs on the Craft Interface
DescriptionStateColorLabel
Fan is functioning normally.On
steadily
GreenFAN
Fan has failed.On
steadily
Red
RELATED DOCUMENTATION
MX960 Craft Interface Overview | 17
MX960 Alarm Relay Contacts on the Craft Interface | 18
MX960 Cable Manager Description
The standard cable manager (see Figure 9 on page 23) is a tray located below the line-card cage, which
has a row of fourteen dividers for securing the cables for each Dense Port Concentrator (DPC), Modular
Port Concentrator (MPC), Modular Interface Card (MIC), or PIC.
