Maintaining MX960 MICs
Purpose
For optimum router performance, verify the condition of the Modular Interface Cards (MICs).
Action
On a regular basis:
•
Check the LEDs on MIC faceplates. The meaning of the LED states differs for various MICs. For more
information, see the MX Series Interface Module Reference. If the MPC that houses the MIC detects a
MIC failure, the MPC generates an alarm message to be sent to the Routing Engine.
•
Issue the CLI show chassis fpc pic-status command. The MIC slots in an MPC are numbered PIC 0/1
and PIC 2/3, top to bottom:
user@host> show chassis fpc pic-status
Slot 0 Online DPCE 4x 10GE R EQ
PIC 0 Online 1x 10GE(LAN/WAN) EQ
PIC 1 Online 1x 10GE(LAN/WAN) EQ
PIC 2 Online 1x 10GE(LAN/WAN) EQ
PIC 3 Online 1x 10GE(LAN/WAN) EQ
Slot 1 Online DPCE 40x 1GE R EQ
PIC 0 Online 10x 1GE(LAN) EQ
PIC 1 Online 10x 1GE(LAN) EQ
PIC 2 Online 10x 1GE(LAN) EQ
PIC 3 Online 10x 1GE(LAN) EQ
Slot 2 Online MS-DPC
PIC 0 Online MS-DPC PIC
PIC 1 Online MS-DPC PIC
Slot 3 Online MPC Type 2 3D EQ
PIC 0 Online 1x 10GE XFP
PIC 1 Online 1x 10GE XFP
Slot 4 Online MPC 3D 16x 10GE
PIC 0 Online 4x 10GE(LAN) SFP+
PIC 1 Online 4x 10GE(LAN) SFP+
PIC 2 Online 4x 10GE(LAN) SFP+
PIC 3 Online 4x 10GE(LAN) SFP+
Slot 6 Online MX960 40GE DPC
PIC 0 Online 10x 1GE
PIC 1 Online 10x 1GE
PIC 2 Online 10x 1GE
PIC 3 Online 10x 1GE
Slot 10 Online MPC 3D 16x 10GE
PIC 0 Online 4x 10GE(LAN) SFP+
