PIC 1 Online 4x 10GE(LAN) SFP+
PIC 2 Online 4x 10GE(LAN) SFP+
PIC 3 Online 4x 10GE(LAN) SFP+
For further description of the output from the command, see the CLI Explorer.
RELATED DOCUMENTATION
MX960 Modular Interface Card Description | 98
MX960 Modular Interface Card (MIC) LEDs | 99
Troubleshooting the MX960 MICs | 662
Replacing an MX960 MIC | 499
Maintaining MX960 MPCs
Purpose
The router can have up to 12 Modular Port Concentrators (MPCs) mounted vertically in the card cage at
the front of the chassis. For optimum router performance, verify the condition of the MPCs.
Action
On a regular basis:
•
Check the LEDs on the craft interface directly above each MPC slot. The green LED labeled OK lights
steadily when an MPC is functioning normally.
•
Check the OK/FAIL LED on the MPC. If the MPC detects a failure, the MPC sends an alarm message to
the Routing Engine.
•
Issue the CLI show chassis fpc command to check the status of installed MPCs. As shown in the sample
output, the value Online in the column labeled State indicates that the MPC is functioning normally:
user@host> show chassis fpc
Temp CPU Utilization (%) Memory Utilization (%)
Slot State (C) Total Interrupt DRAM (MB) Heap Buffer
0 Online 36 3 0 2048 14 13
1 Online 40 5 0 2048 26 13
2 Online 41 6 0 1024 7 43
3 Online 43 5 0 1024 16 57
4 Online 24 3 0 1024 13 21
613
