Juniper MX960 - SCBE-MX Leds

SCBE-MX LEDs
The FABRIC ACTIVE, FABRIC ONLY, and OK/FAIL LEDs indicate the status of the SCBE-MX. The BITS,
GPS, and UTI LEDs (next to the EXT CLK port) indicate the status of the respective clocking interface.
Table 75 on page 167 describes the behavior of the SCBE-MX LEDs.
Table 75: SCBE-MX LEDs
DescriptionStateColorLabel
Fabric is in active mode.On
steadily
GreenFABRIC
ACTIVE
SCBE-MX operates in fabric-only mode.On
steadily
GreenFABRIC
ONLY
SCBE-MX operates in fabric/control board mode.Off–
SCBE-MX is online.On
steadily
GreenOK/FAIL
SCBE-MX has failed.On
steadily
Red
SCBE-MX is offline.Off–
GPS clocking interface has failed.On
steadily
Red
GPS clocking interface is offline.Off–
NOTE: The LEDs BITS, GPS, and UTI are not currently supported.
Building-integrated timing supply (BITS) clocking
interface is active.
On
steadily
GreenBITS
BITS clocking interface has failed.On
steadily
Red
BITS clocking interface is offline.Off–
167
