4. Slide the AS MSC out of the AS MLC card carrier by pulling the handles, and place it in the electrostatic
bag or on the antistatic mat.
5. If you are not reinstalling an AS MSC into the emptied AS MSC slot within a short time, install a blank
AS MSC panel over the slot to maintain proper airflow in the AS MLC card cage.
Figure 167: Removing an AS MSC
SEE ALSO
MX960 Application Services Modular Storage Card Description | 86
Preventing Electrostatic Discharge Damage to an MX960 Router
Installing an MX960 AS MSC | 422
Installing an MX960 AS MSC
To install an AS MSC (see Figure 154 on page 423):
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to the ESD point on the chassis.
447
