Juniper MX960 - MX960 Rack-Mounting Hardware

Figure 6: Midplane
RELATED DOCUMENTATION
MX960 Router Overview | 3
MX960 Chassis Description | 7
MX960 Dense Port Concentrator Description | 63
MX960 Modular Port Concentrator Description | 113
SCB-MX Description | 168
MX960 Routing Engine Description | 30
MX960 Flexible PIC Concentrator Description | 74
MX960 Power System Overview | 129
MX960 Rack-Mounting Hardware
The rack-mounting hardware for the MX960 router includes:
•
The large mounting shelf for mounting in four-post racks, cabinets, and open-frame racks
•
The small mounting shelf for front-mounting in a four-post rack or cabinet
