Preventing Electrostatic Discharge Damage to an MX960 Router
Installing the MX960 Air Filter | 383
Maintaining the MX960 Air Filter | 592
Installing the MX960 Air Filter
To install the air filter (see Figure 134 on page 383):
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to the ESD point on the chassis.
2. Ensure that the air filter is right side up.
3. Place the air filter into the air filter tray.
4. Insert the air filter tray into the chassis by sliding it straight into the chassis until it stops.
5. Lower the cable manager back into position.
6. Rearrange the cables in the cable manager.
Figure 172: Installing the Air Filter
SEE ALSO
Preventing Electrostatic Discharge Damage to an MX960 Router
Removing the Normal-Capacity MX960 Air Filter | 453
Maintaining the MX960 Air Filter | 592
RELATED DOCUMENTATION
455
