Juniper MX960 - Installing an MX960 Dual-Wide MIC

RELATED DOCUMENTATION
MX960 Modular Interface Card Description | 98
Maintaining MX960 MICs | 612
Troubleshooting the MX960 MICs | 662
Removing an MX960 MPC | 510
Removing an MX960 MIC | 499
Preventing Electrostatic Discharge Damage to an MX960 Router
Installing an MX960 Dual-Wide MIC
To install a dual-wide MIC (see Figure 145 on page 402):
1. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to the ESD point on the chassis.
2. Remove the septum, if necessary (see Figure 144 on page 400):
a. Place the MPC on a flat surface (if necessary, remove the MPC from the router as described in
“Removing an MX960 MPC” on page 510).
b. Remove the four screws labeled S on the bottom of the MPC.
c. Remove the two screws labeled S on the top of the MPC.
d. Slide the septum towards you and out of the MPC.
e. Store the septum and screws for later use.
f. Install the MPC as described in “Installing an MX960 MPC” on page 403.
399
