Juniper MX960 - SCBE2-MX Leds

DescriptionComponent
Three LEDs labeled BITS, GPS, and UTI indicate the external clocking interface
status. See Table 73 on page 160.
EXT CLK port LEDs
SCBE2-MX LEDs
Table 73: SCBE2-MX LEDs
DescriptionStateColorLabel
Fabric is in active mode.On
steadily
GreenFABRIC
ACTIVE
SCBE2-MX operates in fabric-only mode.On
steadily
GreenFABRIC
ONLY
SCBE2-MX operates in fabric or control-board
mode.
Off–
SCBE2-MX is online.On
steadily
GreenOK/FAIL
SCBE2-MX has failed.On
steadily
Red
SCBE2-MX is offline.Off–
Building-integrated timing supply (BITS) clocking
interface is active.
On
steadily
GreenBITS
BITS clocking interface has failed.On
steadily
Red
BITS clocking interface is offline.Off–
Global positioning system (GPS) clocking
interface is active.
On
steadily
GreenGPS
GPS clocking interface has failed.On
steadily
Red
GPS clocking interface is offline.Off–
160
