Table 9: DPC and MPC LEDs on the Craft Interface
DescriptionStateColorLabel
Card is functioning normally.On
steadily
GreenOK
Card is transitioning online or offline.Blinking
The slot is not online.Off–
Card has failed.On
steadily
RedFAIL
MX960 FPC LEDs on the Craft Interface
An FPC takes up two DPC slots when installed in an MX Series router. The LEDs, labeled 0 through 5, 2/6,
and 7 through 11, are located along the bottom of the craft interface. Slot 2/6 is for an additional DPC,
FPC, MPC, or SCB. The LED corresponds to the lowest DPC slot number in which the FPC is installed.
Table 10 on page 21 describes the functions of the FPC LEDs.
Table 10: FPC LEDs on the Craft Interface
DescriptionStateColorLabel
FPC is functioning normally.On
steadily
GreenOK
FPC is transitioning online or offline.Blinking
The slot is not online.Off–
FPC has failed.On
steadily
RedFAIL
MX960 SCB LEDs on the Craft Interface
Each SCB has two LEDs on the craft interface that indicates its status. The SCB LEDs, labeled 0, 1, and
2/6, are located along the bottom of the craft interface. Table 11 on page 22 describes the functions of
the SCB LEDs.
