SEE ALSO
MX960 Application Services Modular Storage Card Description | 86
Removing an MX960 AS MSC | 446
RELATED DOCUMENTATION
Preventing Electrostatic Discharge Damage to an MX960 Router
Replacing an MX960 AS MLC | 441
MX960 Application Services Modular Storage Card Description | 86
Replacing an MX960 AS MXC
1.
Removing an MX960 AS MXC | 449
2.
Installing an MX960 AS MXC | 451
Removing an MX960 AS MXC
AS MXCs are hot-insertable and hot-removable. When you remove an AS MXC, the router continues to
function.
The AS MXCs are located in the AS MLCs installed in the front of the router. An AS MXC weighs less than
2 lb (0.9 kg).
To remove an AS MXC (see Figure 169 on page 450):
1. Place an electrostatic bag or antistatic mat on a flat, stable surface to receive the AS MXC.
2. Wrap and fasten one end of the ESD grounding strap around your bare wrist, and connect the other
end of the strap to the ESD point on the chassis.
3. Use one of the following methods to take the AS MXC offline:
•
Press its online/offline button. Use a narrow-ended tool that fits inside the opening that leads to the
button. Press and hold the button until the AS MXC LED goes out (about 5 seconds).
•
Issue the following CLI command:
user@host> request chassis pic fpc-slot fpc-slot pic-slot pic-slot offline
For more information about the command, see the CLI Explorer.
449
