Figure 5: Rear View of a Fully Configured MX960 Router Chassis with Universal High-Voltage
Second-Generation Power Supplies
g100770
1
3
4
6
5
5
2
4—1— Power supply ejectorsAir exhaust
5—2— Grounding pointsPower distribution unit cover
6—3— ESD pointHigh-capacity second-generation AC power supplies
RELATED DOCUMENTATION
MX960 Router Physical Specifications | 177
Installing the MX960 Mounting Hardware for a Four-Post Rack or Cabinet | 255
MX960 Router Grounding Specifications | 197
11
