3. Verify that each transceiver is covered by a rubber safety cap. If it is not, cover the transceiver with a
safety cap.
4. Carefully align the transceiver with the slots in the component. The connectors should face the
component.
5. Slide the transceiver until the connector is seated in the component slot. If you are unable to fully insert
the transceiver, make sure the connector is facing the right way.
6. Close the ejector handle of the transceiver.
7. Remove the rubber safety cap from the transceiver and the end of the cable. Insert the cable into the
transceiver.
WARNING: Do not look directly into a fiber-optic transceiver or into the ends
of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables connected
to a transceiver emit laser light that can damage your eyes.
8. Verify that the status LEDs on the component faceplate indicate that the SFP or XFP is functioning
correctly. For more information about the component LEDs, see the MX Series Interface Module Reference.
SEE ALSO
Preventing Electrostatic Discharge Damage to an MX960 Router
Removing an SFP or XFP Transceiver from an MX960 DPC, MPC, MIC, or PIC | 527
Replacing an MX960 PIC | 517
Replacing an MX960 DPC | 485
