Check the status of each port on a MIC by looking at the LED located on the MIC faceplate. For
information about the meaning of LED states on different MICs, see the MX Series Ethernet Services
Routers Line Card Guide.
•
Check the status of a MIC by issuing the show chassis fpc pic-status CLI command. The MIC slots in
the MPC are labeled PIC 0/1 and PIC 2/3, top to bottom:
user@host> show chassis fpc pic-status
Slot 0 Online DPCE 4x 10GE R EQ
PIC 0 Online 1x 10GE(LAN/WAN) EQ
PIC 1 Online 1x 10GE(LAN/WAN) EQ
PIC 2 Online 1x 10GE(LAN/WAN) EQ
PIC 3 Online 1x 10GE(LAN/WAN) EQ
Slot 1 Online DPCE 40x 1GE R EQ
PIC 0 Online 10x 1GE(LAN) EQ
PIC 1 Online 10x 1GE(LAN) EQ
PIC 2 Online 10x 1GE(LAN) EQ
PIC 3 Online 10x 1GE(LAN) EQ
Slot 2 Online MS-DPC
PIC 0 Online MS-DPC PIC
PIC 1 Online MS-DPC PIC
Slot 3 Online MPC Type 2 3D EQ
PIC 0 Online 1x 10GE XFP
PIC 1 Online 1x 10GE XFP
Slot 4 Online MPC 3D 16x 10GE
PIC 0 Online 4x 10GE(LAN) SFP+
PIC 1 Online 4x 10GE(LAN) SFP+
PIC 2 Online 4x 10GE(LAN) SFP+
PIC 3 Online 4x 10GE(LAN) SFP+
Slot 6 Online MX960 40GE DPC
PIC 0 Online 10x 1GE
PIC 1 Online 10x 1GE
PIC 2 Online 10x 1GE
PIC 3 Online 10x 1GE
Slot 10 Online MPC 3D 16x 10GE
PIC 0 Online 4x 10GE(LAN) SFP+
PIC 1 Online 4x 10GE(LAN) SFP+
PIC 2 Online 4x 10GE(LAN) SFP+
PIC 3 Online 4x 10GE(LAN) SFP+
For further description of the output from the command, see the CLI Explorer.
