JVL Industri Elektronik A/S - User Manual - Integrated Stepper Motors MIS23x, 34x, 43x 193
9.4 How to build a program
TT0985GB
Now the program is running
continuously. The actual program
line which is executed is shown
by the small red arrow.
By choosing the “Pause” button, the
program is paused. After it is paused,
it is possible to single step through
each program line which can be a
useful feature to debug the program
since the action in each line can be
closely observed.
When the program is finished, it can
be saved on the harddisc or floppy
disc. Please be aware that when
saving the program it is the complete
program including the overall setup
of the motor such as servofilter, I/O
setup etc. Everything is stored in a file
with the extension . Later it can
be opened and restored in the motor.
.MAC
10
11
12
