6 I/O terminals
6.1 Digital input terminals
330
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Short overview of the parameters for the frequency inputs:
Parameters Info Lenze setting
Value Unit
C00011 Appl.: Reference speed 1500 rpm
Frequency input DI1/DI2
C00115/1
Fct. DI 1/2 200kHz 0: DI1(6)=In / DI2(7)=In
C00420/1
Encoder increments at FreqIn12 128 Incr./rev.
C02842/1
FreqIn12: Offset 0.00 %
C02843/1
FreqIn12: Gain 100.00 %
C02844/1
PosIn12: Function Loading with level
C02845
PosIn12: Comparison value 0
C00443/1 DIx: Terminal level -
C00445/1 FreqIn12_nOut_v - Incr/ms
C00446/1 FreqIn12_nOut_a - %
C00449/1 FreqIn12_dnOut_p - Incr
Frequency input DI6/DI7
C00115/2
Fct. DI 6/7 10kHz 0: DI1(6)=In / DI2(7)=In
C00420/2
Encoder increments at FreqIn67 128 Incr./rev.
C02842/2
FreqIn67: Offset 0.00 %
C02843/2
FreqIn67: Gain 100.00 %
C00443/1 DIx: Terminal level -
C00445/2 FreqIn67_nOut_v - Incr/ms
C00446/2 FreqIn67_nOut_a - %
Greyed out = display parameter
