161: Set Analog Smoothing Factor

This command allows you to smooth the analog readings to "average out" noise and sudden

changes.

<161> l ss

Parameters:

- 161 is the default command name

- L is the analog input line

- SS is the smoothing factor

Smooth Factor Average Smooth Time

50 about 9 seconds

60 about 13 seconds

70 about 18 seconds

80 about 30 seconds

90 about 50 seconds

95 about 120 seconds

97 about 220 seconds

98 about 325 seconds

99 about 11 minutes
