151: Turn Radio Power On or Off for RBI-1

This command allows you to use the Doug Hall RBI-1 to turn the radio's power off, if the radio

supports it. It does not work with the RLC-ICM, only with the Doug Hall RBI-1.

<151> 0 Radio Power Off

<151> 1 Radio Power On

Parameters:

- 151 is the default command name.

Example:

I want to turn off the power on my 2 meter radio

<151> 0

Voice Response:

"Radio Power <ON/OFF>"
