6-3
Version 1.73 Copyright © 1997 Link Communications Inc. 1/18/97
031: Send a DTMF Sequence
This command allows you to send DTMF tones. They will be sent to the ports that are in the
audio routing variable at the time this command is executed (for more info, see Appendix A).
See Command 044 to set up the length of the tones and pauses between tones.
<031> DD..DD
Parameters:
- 031 is the default command name.
- DD is the DTMF data (See Below)
Number DTMF Digit
00 0
01 1
02 2
03 3
04 4
05 5
06 6
07 7
08 8
09 9
10 A
11 B
12 C
13 D
14 *
15 #
16 <Pause>
Example:
Want to send the DTMF data '0 0 0 1 1 D'
<031> 00 00 00 01 01 13 D or unkey or <Enter>
