4-16

028: Sets the Date

This command allows you to set the date on the RLC-Club Clock.

<028> mm dd yy w

Parameters:

- 028 is the default command name.

- MM is the month with leading zeros

- DD is the day of the month with leading zeros

- YY is the last two digits of the year

W is the day of the week

Number Day

1 Sunday

2 Monday

3 Tuesday

4 Wednesday

5 Thursday

6 Friday

7 Saturday

Example:

Want to set the date to January 2, 1996

<028> 01 02 96 3

Default Chapter5
- Table of Contents5
Command List by Command Number13
Limited Warranty17
Regulatory Information18
- Telephone Grounding Precautions18
User Survey (Optional)19
Chapter 1: Getting Started21
- Setup, Interfacing and Adjustment21
- What each Connector Is for21
- What the Led's Represent22
- Serial Port Interfacing28
- Windows TM Programming32
- Reset and Power up33
- Entering Commands33
- Error Messages35
- How to Configure a Port as a Repeater37
- Example 1-1: Configuring a Port as a Repeater, Link38
- Example 1-2: Configuring a Port's COR/PL Polarity39
- Troubleshooting the Controller40
Chapter 2: Port Connection Commands41
- Connected Ports41
- Turning a Repeater off41
- 000: Connect One Port to Another Port43
- 001: Monitor One Port from Another Port44
- 002: Disconnect One Port from Another Port45
- 003,004: Recall a Port's Connections46
- 005,006: Set Up/Recall a Port's Access Mode47
- 009: Recall Entire Controller's Audio Crosspoint48
- 013: Set COR and PL Active Levels49
- 061: Disconnect All Ports from a Radio Port50
- 155: Enable or Disable PTT for a Port51
- 156: Recall Which PTT Are Enabled51
Chapter 3: Audio and DTMF Configurations53
- 007: Configure DTMF Mute/Cover Tone/Bypass55
- 008: Check DTMF Mute/Cover Tone/Bypass Settings56
- 168: Set DTMF Acceptance Requirements56
Chapter 4: Timers57
- 020: Program a Selected Timer58
- 021: Recall a Timer Value69
- 022: Restart a Selected Timer69
- 023: Reset a Selected Timer69
- 025: Sets the Time of Day Clock70
- 026: Recall the Time of Day Clock in Male Speech70
- 027: Recall the Time of Day Clock in Female Speech71
- 028: Sets the Date72
- 029: Recall the Date73
Chapter 5: Command Names75
- How Command Names and Command Numbers Are Used75
- 010: Re-Program Command Names79
- 062: Change the Beginning of Command Names81
- 011: Recall Command Name82
- 012: Find Commands Named82
- Blocking Execution from Certain Ports83
- 130: Block Command Execution from Port84
- 131: Allow Command Execution from Port84
- 132: Recall Blocked Ports84
Chapter 6: CW, DTMF, Voice and DVR Messages85
- 030: Send a CW Message86
- 031: Send a DTMF Sequence87
- 036: Send a Voice Message88
- 066: Send a Voice Message Using English Words88
- 040: Send One or Two Tone Sequence89
- Note about Courtesy Beeps90
- 041: Courtesy Beep Enable/Disable for a Selected Transmitter92
- 042: Set CW Speed for a Selected Port93
- 043: Set CW 2-Tone Frequencies for a Selected Port94
- 044: Set up DTMF Regenerate Parameters95
- 051: Start Dial-Tone95
- 063: Send a Polite Voice Message96
- 064: Send a Polite Voice Msg, if Interrupted Execute CMD97
- 163: Keypad Test98
- The DVR1 Digital Voice Recorder99
  - What the DVR1 Is99
- 170: Record and Play Audio Test106
- 171: Record DVR Track (Non-Prompted)106
- 172: Record DVR Track (Prompted)107
- 173: Play DVR Tracks107
- 174: Erase DVR Tracks108
- 175: Record Public Mail109
- 176: Check Public Mailboxes109
- 177: Retrieve Public Mail109
- 178: Erase Public Mail110
- 179: Record Private Mail110
- 180: Retrieve Private Mail110
- 181: Erase Private Mail111
- 182: Enable/Disable RLC-DVR1111
- The Internal Digital Voice Recorder112
- 183: Record a Message on the Internal DVR113
- 184: Playback an Internal DVR Message(S)114
- 185: Erase Internal DVR Message(S)114
- 052: Audio Test Using the Internal DVR115
- 034: Adjust each Port's Internal DVR Record Level116
Chapter 7: Serial Port Commands117
- 024: Set up RS-232 Serial Baud Rate119
- 060: Set up Serial Port Options120
- 032: Send Serial Message out the Main Serial Port121
- 162: Always Send Serial Message out the Main Serial Port121
- 169: Always Send Serial out Main Serial Port by ASCII Code122
- 138: Direct SPI Send Using Output Lines123
Chapter 8: Macros125
- How Macros Get Executed125
- What a Macro Is125
- Limits on Macros126
- 200..499: Execute a Macro128
- 053: Program a Single Command Macro Sequence129
- 054: Recall Macro Contents130
- 055: Delete Macro131
- 056: Append a Command to a Macro131
- 057: Copy a Macro131
- 058: Delete a Command in a Macro132
- 059: Insert a Command in a Macro132
- Automatic Macros133
Chapter 9: Pre-Access Commands145
- What Preaccess Is145
- What You Need to Know145
- 049: Configure a Port's Tone Response When in Preaccess146
- 070: Configure a Repeater for Preaccess147
- 071: Configure a Link for Preaccess148
- 072: Disable Preaccess Requirement for a Port149
- 073: Recall Ports with Preaccess Requirement149
- 074: Allow Access to a Port that Requires Preaccess149
- 075: Set Stop Access Conditions150
- 076: Recall Stop Access Conditions151
- 077: Isolate a Port from the Rest of the System151
Chapter 10: Scheduler153
- How the Scheduler Works153
- 082: Set up a Scheduler Event154
- 083: Recall a Scheduler Event157
- 084: Enable/Disable a Scheduler Event158
Chapter 11: The ID System159
- How the ID's Work159
- Polite Voice ID's159
- To Program Your Own ID's160
- More about Programming ID's160
- ID Timing161
- 085: Enable/Disable Iding a Port162
- 086: Recall Which Ports Have ID's Enabled162
- 086: Recall Which Ports Have Ids Enabled162
  - 087: Set Random or Rotating Pending ID's163
- 087: Set Random or Rotating Pending Ids163
  - 088: Recall Random or Rotating Pending ID Selection163
Chapter 12: I/O System165
- About the I/O System165
- Logical Output Lines165
- Analog Input Lines165
  - Inputs Connector Pin-Out167
- 090: Read Whether Input Line Is High or Low168
- 091: Execute Input Line High or Low Macro168
- 092: Enable/Disable Input Line Alarm169
- 093: Turn Output Line on170
- 094: Turn Output Line off170
- 095: Recall Whether Output Line Is on or off171
- 100: Read Analog Input Line172
- 101: Set Resolution for Analog Input173
- 102: Set Conversion Ratio for Analog Input175
  - Custom Analog Conversion Ratios176
- 103: Calibrate an Analog Input178
- 104: Set an Analog Alarm179
- 105: Set Analog Alarm Hysteresis180
- 106: Enable/Disable an Analog Alarm182
- 107: Recall Analog Lines in Alarm182
- 108: Recall Analog Line Configuration183
- 160: Clear Analog High/Lows184
- 161: Set Analog Smoothing Factor185
Chapter 13: Autopatch Routines187
- Configuring the Autopatch187
- Autopatch up Commands187
- Using '*' for the Autopatch up Command187
- Hanging up187
- Connected Ports188
- Predial Digits188
- The Autodialer188
- Limiting Call Length189
- How the Dialing Tables Work189
- Other Commands that Affect the Autopatch190
- 110: Configure the Autopatch191
- 111: Manual off Hook193
- 112: Normal Forward Dial193
- 113: Forward Dial with no Long Distance Checking194
- 114: Hang up the Autopatch195
- 115: Possibly Hang up the Autopatch195
- 116: Set / Recall the Predial Digits and Timing196
- 119: Set Allowed Numbers Table Slot197
- 120: Recall Allowed Numbers Table Slot197
- 121: Set Nuisance Numbers Table Slot198
- 122: Recall Nuisance Numbers Table Slot198
- 123: Test Dialing Tables199
- 124: Set Autodial Slot200
- 125: Recall Autodial Slot200
- 126: Send Predial Digits / Callsign for Autodial Slot201
- 127: Enable/Disable an Autodial Slot201
- 128: Set Full or Half-Duplex Patch Audio for a TX202
- 129: Recall Full or Half-Duplex Patch Audio for a TX202
- 133: Set up Reverse Patch203
- 134: Access Reverse Patch Control Mode204
- 135: Answer Reverse Patch204
- 136: Set up Reverse Autopatch Ring205
- 137: Autodial Only205
Chapter 14: Doug Hall RBI-1 and RLC-ICM Routines207
- What the RBI-1 Is207
- What the RLC-ICM Is207
- Using the RBI-1 or RLC-ICM208
- 139: Setup RLC-Icom Interface208
Chapter 15: Serial Controlled (HF) Radio Support229
- HF Radio Interfacing229
- HF Radio Control230
- 195: Configure HF Mode232
- 196: Configure HF Radio233
- 197: Set/Recall Transmit/Scan Band Edges235
- 198: HF Mode Enable237
  - HF Remote Base Keypad Definition238
Chapter 16: Special Audio Routing Commands245
- 037: Set Audio Routing Variable for Commands in a Macro246
- 038: Kill All Responses Following this Command247
- 065: Restore Audio Routing Variable (Undo 037 and 038)248
- 039: Recall the Ports in the Current Audio Routing Variable249
- 050: Set up or Recall Default Audio Routing Variables250
Chapter 17: Special Control Commands253
- 035: Remotely Reset the Controller254
- 078: Set Command Entry Options for a Port255
- 079: Recall Command Entry Options for a Port257
- 164: Recall Software Version258
- 165: Reset COP Watchdog Timer258
- 166: Display Status Screen259
- 167: Do Nothing259
- 014..019: Not Currently Used260
- 033, 034: Not Currently Used260
- 080, 081: Not Currently Used260
Chapter 18: 500 User Structure261
- The Password System261
- 186: Set up User Password266
- 187: User Log-On267
- 188: Recall Who Is Logged in268
- 189: User Log-Off268
- 190: Assign a User Level to a Command269
- 191: Assign a Callsign to a User270
Chapter 19: The Beaconing System271
- 045: Setup Beacon Table272
- 046: Start Beacon273
- 047: Cancel Beacon273
- 048: Start Beacon Using English Words273
Chapter 20: Event Triggers275
- 157: Set up Event Trigger276
- 158: Recall Event Trigger Setting276
- 159: Enable/Disable Event Trigger276
Appendix A: the Audio Routing Variable System279
- Explanation of the System279
- Suppressing Command Responses in Macros280
Appendix B: Voice Word Table281
Appendix C: CW Code Table289
Appendix D: Reset and Initialization291
Appendix E: Not Currently Used293
Appendix F: Programming with the Serial Port295
- Voice Responses to Commands Entered Serially296
- Using a Serial Upload File296
- Note about Spaces in Serial Commands297
- Note about Comments in Serial Upload Files297
- Note about Capital Letters297
- Note about Download Speeds297
- Serial Responses to Commands Entered from a Radio298
- Very Long Serial Commands299
Appendix G: ASCII Chart301
Appendix H: Using the LM335 Temperature Sensor302
Appendix I: Software Problem and Request Form304
Appendix J: Hardware Reference Section308
- Important Connections308
  - RLC-Club Main Board308
  - RLC-Club Deluxe Module309
- Bill of Materials315
  - RLC-Club Deluxe315
- Component Layouts and Schematic Diagrams318

Questions and Answers:

Need help?

Do you have a question about the Link Communications RLC-CLUB and is the answer not in the manual?

Link Communications RLC-CLUB Specifications

General

Brand	Link Communications
Model	RLC-CLUB
Category	Controller
Language	English

Related product manuals

Link Communications RLC-4

228 pages

Link Communications RLC-CLUB User Manual

Table of Contents

Questions and Answers:

Link Communications RLC-CLUB Specifications

Related product manuals
