ASSEMBLING THE W INDROWER
17. Disengage safety prop by turning lever (A) downwards
to release and lower stop until lever locks into
vertical position.
18. Repeat for opposite safety prop.
Figure 3.231: Safety Prop
CAUTION
Check to be sure a ll bystanders have cleared t he area.
19. Start the eng ine and activate the HEADER DOWN
switch (A) on the GSL to fully lower the header.
20. Stop engine and remove key from ignition.
Figure 3.232: Ground Speed Lever
21. Connect
header drive hoses (A) and electrical
harness
(B) to header. Refer to the auger header
operat
or ’s manual.
Figure 3.233: Header Drive Hoses and Harness
147962 126 Revision A
