ASSEMBLING THE WINDROWER
CAUTION
Check to be sure all bystanders have cleared the area.
18. Start the e ng ine a nd activa te the HEADER DOWN
switch (A) on the GSL to fully lower the hea de r.
19. Stop engine and remove key from ignition.
Figure 3.245: Ground Speed Lever
20. Connect h
eader drive hoses (A) and electrical
harness (
B) to header. Refer to the draper header
operator
’s manual.
Figure 3.246: Heade r Drive Hose s and Harnes s
147962 131 Revision A
