CAB DISPLAY MODULE (CDM)
6. Press SELEC T (D) until DRAPER SPEED is displayed
on the upper line.
• ENABLED/LOC KED is displayed on t he lower line.
7. Press left arrow (B) to enable DRAPER SPEED control
switch, or press right arrow (C) to lock DRAPE R
SPEED control switch.
8. Press PROGRAM (A) to ex it Programming Mode or
press SELECT (D) to proceed to next WINDROWER
SETUP action.
Figure 4.1
82: M105 Draper Control Lock
Figure
4.183: M 155 Draper Control Lock
Figure 4.184: M205 Draper Control Lock
147962 233 Revision A
