CAB DISPLAY MODULE (CDM)
CAUTION
Check to be sure a ll bystanders have cleared t he area.
9. Press SELECT (D) until HDR TILT IN/OUT is displayed
on the lower line.
10. P ress SELECT (D) until A CTIVATE HDR TILT is
displayed on the upper line.
• IN/OUT is displayed on th e lower line.
11. Press and hold left (B) arrow to decrease header tilt.
Press and hold right (C) arrow to increase header tilt.
Verify header is functioning properly.
12. Press PROGRAM (A) to exit Programming
Mode or press SELECT (D) to proceed to next
ACTIVATE FUNCTION.
Figure 4.300: M105 Header Tilt Angle
Figure 4.301: M155 Header Tilt Angle
Figure 4.302: M205 Header Tilt Angle
147962 282 Revision A
