ASSEMBLING THE WINDROWER
4. Remove tie bar (A) between the two caster wheels.
Figure 3.20: Caster Wheel Shipping Assembly
5. Remove the two caster supports (A) from the caster
wheels and frame. Retain bolts for attaching c aster to
walking beam .
Figure 3.21: Caster Supports
147962 37 Revision A
