Operating elements for driving
3.2 Brief description of the operating elements
Operating manual 3 302 819 en 3 - 51
GMK3060
13.12.2018
Exiting the menu/input mode
Overview menu groups
Sensor – no function
à Display – setting the brightness, p. 4 - 11.
Display temperature warning display
The temperature of the control unit is measured by an internal sensor.
s
1 Press: – The opened menu closes – the menu from the next higher
level is opened.
– Input mode is deactivated.
1 Press: – After the first press
Menu groups overview display
– After a subsequent press
Next/previous group overview
– Blue, flashing: Temperature too low – display will not be switched on
Temperature too high:
– Red, lights up: Brightness is reduced
– Yellow, flashing: Display is switched off
– Red, flashing: Control unit is switched off
à p. 4 - 11
