Driving mode
5.1 Before driving
5 - 8 3 302 819 en Operating manual
GMK3060
13.12.2018
Warning plates for
vehicle width
Depending on the vehicle width and version, fold-up warning plates are fitted
below the driver's cab.
The warning plates (1) must be folded down to
indicate the vehicle width during on-road driving.
For off-road driving, the warning plates can be
folded up and fastened with the locking bar (2).
Checking the
vehicle height
The vehicle height given at on-road driving level is only maintained when the main
boom is resting in the boom rest;
à p. 1 - 8.
If the Vehicle height check function is present, the position of the main boom in the
boom rest is monitored. In this case, a corresponding warning is shown on the
CCS display if the main boom has not been correctly set down;
à p. 8 - 15.
S
Risk of accidents by exceeding total permissible height!
Check whether the main boom is resting on the boom rest.
Otherwise the indicated total height will also be exceeded at on-road level.
