Malfunctions in driving mode
8.5 Emergency operation and breakdown assistance
Operating manual 3 302 819 en 8 - 35
GMK3060
13.12.2018
Removing a wheel
• Remove the nuts (1).
• Lift the spare wheel off the holder.
• Secure the spare wheel against falling over if
you put it down temporarily.
Mounting a wheel
• Lift the wheel on to the holder.
• Secure the wheel with the nuts (1) and tighten
them to 500 Nm (370 lbf ft).
Mounting a wheel
• Check that the bearing surfaces of the wheel rim and hub are clean (no paint,
grease or oil).
• Lightly grease the wheel studs.
• Place the wheel at the hub in an upright position.
• Extend or retract the outrigger cylinders until the holes in the wheel rims are in
line with the wheel studs.
• Push the wheel on to the wheel studs. Make sure the threads of the wheel studs
are not damaged.
s
G
Risk of accidents!
Check the wheel rim, tyres, lug nuts and wheel studs for damage before
mounting the spare wheel.
Damaged parts may not be mounted!
Mount only the original wheel supplied by
Manitowoc Crane Group Germany
GmbH
or an approved wheel of the same size and load bearing capacity!
