Overview
1.5 Technical data
1 - 14 3 302 819 en Operating manual
GMK3060
13.12.2018
Steering Dual-circuit hydraulic steering with engine-independent emergency steering
pump
Tyres 6 x 385/95 R 25 on disc wheels 9.50-25/1.7
6 x 445/95 R 25
1)
on disc wheels 11.00-25/1.7
6 x 525/80 R 25
1)
on disc wheels 17.00-25/1.7
Torque for wheel nuts: 650 Nm (480 lbf ft).
Tyre pressure;
à Maintenance manual.
Turning radii All dimensions in the illustration are in mm.
1)
Additional equipment
R = values for normal steering mode
Ra = values for all-wheel steering
R 5100
Ra 2720
R 7985
Ra 6320
R 11300
Ra 8400
R 10530
Ra 7485
R 11835
Ra 8860
