Operating elements for crane operation
9.3 Short description of the operating elements – driving from the crane cab
Operating manual 3 302 819 en 9 - 157
GMK3060
13.12.2018
Steering mode switched on display
Shows the symbol for the currently selected steering mode.
The switching procedure for the selected steering mode has been initiated.
The current switching status is displayed on the Steering locking status display.
Steering locking status display
Indicates whether the switching procedure for the
selected steering mode has been completed.
s
Selected steering mode Gear change
1 Normal steering mode – on-road
driving
Locking the steering
2 Separate steering – manual Unlock steering
3 Separate steering – driving around
corners
Unlock steering
4 Separate steering – crab travel
mode
Unlock steering
1 Green – locked
2Red – unlocked
3 Yellow – intermediate position
4 Error
