Crane operation
11.4 Operation of the rated capacity limiter
11 - 68 3 302 819 en Operating manual
GMK3060
13.12.2018
When rigging For rigging work, you can:
– Override the lifting limit switch;
à p. 11 - 89
or
– override the RCL and thus enable a degree of utilisation of up to 110%.
RCL override
• Press the button (1) once – the information
message (2) is displayed.
– Now a degree of utilisation of up to 110% is
enabled.
– If you do not trigger a control lever movement
within 10 seconds after the override, you must
press the button (1) again.
– The power unit speeds are reduced to 15%.
Cancelling the override
The override will be cancelled when you:
– press button (1) again, or
– do not activate the control lever for 10 seconds, or
– switch off the ignition.
S
Risk of accidents if the RCL is overridden!
It is not permitted to work with an overridden RCL!
Use this type of override only for rigging.
