Crane operation
11.4 Operation of the rated capacity limiter
11 - 70 3 302 819 en Operating manual
GMK3060
13.12.2018
In emergencies During this type of override, the complete shutdown of the RCL is cancelled and
no monitoring takes place.
Cancelling a shutdown
• Insert the key into the key-operated switch (1).
• Turn the key to the left or right once.
The status display (3) will flash red.
The information display (2) appears.
– All crane movements are enabled for
30 minutes.
– The speed of the movements which increase
the load moment is reduced to 15%.
– At a degree of utilisation over 110% the
warning signal will sound.
Cancelling the override
The override will be cancelled when you:
– Switch off the ignition
– Press the key-operated switch again.
The override will automatically be cancelled 30 minutes after the key-operated
switch has been pressed.
G
Risk of accidents due to overridden or faulty RCL!
It is not permitted to work with an overridden or faulty RCL!
Set down the load immediately and stop operating the crane if the RCL is faulty!
You may only override the RCL if it becomes absolutely necessary in the event
of an emergency. This is to put the truck crane into a safe state in the event of a
malfunction. In this case, do not perform any movements that would increase the
load moment.
S
Risk of accidents due to unintentional override!
The key must not remain in the key-operated switch while the crane is operating!
This prevents the RCL being overridden unintentionally.
