Crane operation
11.5 Crane operation with main boom
Operating manual 3 302 819 en 11 - 87
GMK3060
13.12.2018
You can adjust the desired engine speed (idling speed) with button (1);
à p. 10 - 9.
Maximum
permissible hoist
rope speed
The maximum permissible hoist rope speed is limited automatically depending
on the degree of utilisation of the lifting capacity and reeving. The scale of the
limitation is specified in the supplied Lifting capacity table.
The current speed reduction is displayed in the start menu;
à p. 9 - 21.
You can limit the maximum hoist speed in the Power unit speed menu;
à p. 11 - 131.
Switching off the
auxiliary hoist
If the auxiliary hoist is not required, it should be switched off to avoid unintentional
use.
• Press the button (1) once.
– The lamp in the button (1) will light up dimly.
–Symbol (2) is red when the auxiliary hoist is switched off.
