Overview
1.7 Notes on the operating manual
Operating manual 3 302 819 en 1 - 27
GMK3060
13.12.2018
The parking brake is used as an example to show how the cross-references guide
you through the operating manual.
A In this example, the general overview is shown on page 3 - 2.
The driver's cab is labelled as number 1. The related table contains a
cross-reference in the form
1 Driver's cab
à p. 3 - 4
B Pages 3 – 4 show an interior view of the driver's cab.
The parking brake is labelled as number 2. The related table contains a
cross-reference in the form
2 Parking brake
à p. 3 - 52
C Pages 3 – 52 give a brief description of all the functions of the parking brake.
If further information is available, the brief description contains a
cross-reference, for example,
4 Test posi-
tion for tow-
ing a trailer:
– Pull the lever down until it locks into place
– Press in the lever and pull it further downwards
The parking brake for the trailer is released;
à p. 5 - 90.
D Follow the cross-reference to pages 5 - 90. Here, the test position of the
parking brake when towing a trailer is described in detail, with all require-
ments and safety instructions.
There may be additional cross-references here, such as to related pages in
the chapter Malfunctions.
