Crane operation
11.5 Crane operation with main boom
11 - 106 3 302 819 en Operating manual
GMK3060
13.12.2018
You can switch on the high-speed mode for a higher speed; Ã p. 11 - 119.
You can adjust the desired engine speed (idling speed) with button (1);
à p. 10 - 9.
You can limit the maximum telescoping speed in the Power unit speed menu;
à p. 11 - 131.
Switching off
the telescoping
mechanism
If the telescoping mechanism is not required, it should be switched off to avoid
unintentional use.
• Press the button (1) once.
– The lamp in the button (1) will light up dimly.
– The symbol (2) red if the telescoping mechanism is switched off.
If the control lever is assigned more than one function, the telescoping mecha-
nism will also be switched off if you switch on another power unit which is
assigned to the same control lever movement;
à Control lever configuration,
p. 9 - 14.
