Crane operation
11.5 Crane operation with main boom
11 - 124 3 302 819 en Operating manual
GMK3060
13.12.2018
H
With the Brake pedal function switched on, slewing movements are not braked
automatically. If you let go of the control lever or move it to initial position, the
slewing movement will slowly run down;
à Braking the slewing movement,
p. 11 - 125.
You can regulate the speed by moving the control lever and changing the engine
speed with the accelerator.
You can adjust the desired engine speed (idling speed) with button (1);
à p. 10 - 9.
The current slewing angle is shown in the Start menu and in the Superstructure lock
menu.
0° means that the superstructure is slewed to the rear.
– Angles in the right-hand semi-circle are displayed as positive values
(0° to +180°).
– Angles in the left semi-circle are displayed as negative values
(0° to - 179.9°).
Maximum slewing
speed
The current speed reduction is displayed in the Start menu;
à p. 9 - 21.
The maximum permissible slewing speed is limited automatically depending on
the working radius and degree of utilisation of the lifting capacity. Under certain
circumstances, you can switch off this reduction;
à p. 11 - 127.
You can limit the maximum slewing speed in the Power unit speed menu;
à p. 11 - 131.
Slewing to the left:
• Push the control lever to the left.
Slewing to the right:
• Push the control lever to the right.
