Rigging work
12.6 Rigging/unrigging the counterweight
Operating manual 3 302 819 en 12 - 67
GMK3060
13.12.2018
Counterweight sections in t (lbs)
Counterweight
combination
in t (lbs)
1.0
(2,205)
1
2.0
(4,410)
2
1.0
(2,205)
3
7.6
(16,755)
4
1.0
(2,205)
5
8.6
(18,900)
–––●●
1)
9.6
(21,160)
––●
2)
●●
1)
● ––●●
1)
10.6
(23,360)
– ●
2)
– ●●
1)
● – ●
3)
●●
1)
11.6
(25,500)
● 2 x
4)
●●
1)
●●
3)
– ●●
1)
12.6
(27,770)
●●
5)
●
5)
●●
1)
13.6
(29,980)
●●
5)
2 x
5)
●●
1)
1)
1 x 6 can also be used instead of 1 x 5
2)
Must be installed on the turntable
3)
Can also be installed on the turntable
4)
1 x 3 can be installed on the turntable
5)
1 x 3 or 1 x 2 can be installed on the turntable
