Rigging work
12.6 Rigging/unrigging the counterweight
Operating manual 3 302 819 en 12 - 75
GMK3060
13.12.2018
For version A
A maximum of two 2.0 t sections (2) may be
placed on the 1.0 t base plate (1).
For version B
A maximum of one 2.0 t section (3) and one 1.0 t
section (2) may be placed on the 1.0 t base
plate (1).
